Waters 717plus - Changing Syringe Volume

Maintenance 134
5
Modifying Configuration Parameters
If the replacement syringe is a different size, change the syringe volume on Configuration
Page 3.
To modify the syringe volume parameter:
1. Access Configuration Page 3 by pressing the keys indicated in Figure 5-5
.
Figure 5-5 Changing Syringe Volume
Standard Optional
250 µL 25 µL or 2.5 mL
Menu: Main
Configuration
Page 1
Config
Page
NextCfg
Page
Configuration
Page 2
NextCfg
Page
IDLE
Edit: Configuration Page 3 of 4
Draw Rate ( 1/sec) :
Syringe Volume ( 1) ?
Loop Volume ( 1) ?
Halt Bad Comp Check?
Report Delay (min) :
PrevCfg
Page
Yes
250
200
Yes
3.0
2.50
2500
2000
No
20
NextCfg
Page
Main
Page
Yes
25
0
Yes
3.0
25
