Waters 717plus - Removing the Autosampler Cover

Installation 48
2
Figure 2-7 Removing the Autosampler Cover
123456789101112131415
PROG EVENT
RS-232
IEEE-488
INJECT STOP
INJECT START
INJECT START
HOLD
HOLD
NEEDLE WASH IN (1/16") GREEN
NEEDLE WASH OUT (1/16") YELLOW
NEEDLE LINE OUT (1/16") CLEAR
Posts
4. Lift up
cover.
3. Pull
cover back
to clear
posts, fluid
lines, and
front
flanges.
2. Remove
cover
retaining
screw.
1. Lift up
syringe
cover to
remove.
Side Flanges
Front Flanges
Side Slots
(for Fluid Lines)
