Specifications 162
A
Table A-2 Mechanical Specifications
Condition Specification
Wetted Surface Materials 316 Stainless Steel, Teflon
®
, Glass, Fluo-
raloy-08 R, UHMWPE
Number of Sample Vials 1 to 96
Number of Injections Programmable 1 to 99 injections per vial
Allowable Solvents All standard LC solvents
Inlet Tubing to Injector 0.040 I.D. stainless steel
Outlet Tubing from Injector 0.009 I.D. stainless steel
Total Solvent Volume 836 µL
Weight 63 lbs. (28.6 kg)
Dimensions 15” width x 16” height x 21” depth (38.10 x
40.64 x 53.34 cm)
Table A-3 Environmental Specifications
Condition Specification
Operating Temperature Range 4 to 40 °C
Note that the cooler performance is derated
when the ambient operating temperature
exceeds 27 °C.
Relative Humidity 80%, noncondensing
Storage Temperature Range –40 to 70 °C
Table A-4 Power Requirements
Voltage Range (Vac) Frequency (Hz) Current
100 to 240
Grounded ac outlet
50 or 60 Hz 5 A maximum
