Waters 717plus - Operating Conditions; Power Requirements

Installation 34
2
Figure 2-1 Waters 717plus Autosampler Site Requirements
Operating Conditions
Locate the Waters 717plus Autosampler in a clean area free from extremes in
temperature, humidity, strong radio frequency radiation, appreciable shock or vibration.
The Waters 717plus Autosampler operates within the following ranges:
Do not locate the Waters 717plus Autosampler in direct sunlight, near heat registers, or
under air conditioning vents.
Weight
Requires a bench capable of supporting at least 75 pounds.
Power Requirements
Requires 5 amps at 110 Vac (nominal) or 4 amps at 220 Vac (nominal) from a grounded
outlet.
Temperature
4 to 40 °C
Note that cooler performance is derated above 27 °C
Humidity
80% maximum relative humidity, noncondensing
1
2
3
4
5
6
7
8
9
0
Home
Clear
Enter
CAROUSEL
Engage
Release
21 inches (53 cm)
23.5 inches
(59 cm)
Rear
Ventilation
3.5 inches
(8.8 cm)
Side Ventilation
2.5 inches (6 cm)
