Waters 717plus - 3.2 Using the Front Panel

Startup and Configuration 56
3
Figure 3-2 Main Menu
Adjusting Display Contrast
If you do not see the Main menu, or need to improve readability, adjust the screen display
contrast as follows:
• If the screen appears blue in color, press the Display Contrast Up arrow (see
Figure 3-3
) until the screen text is in focus.
• If the screen appears white in color, press the Display Contrast Down arrow (see
Figure 3-3
) until the screen text is in focus.
3.2 Using the Front Panel
Use the front panel (Figure 3-3) to configure the 717plus system and perform injection
programming.
This section describes:
• Accessing menus using menu function keys
• Entering operating parameters using the keypad
IDLE
Menu: Main
Waters 717 Plus Autosampler
Rev. 2.0C
Heater/Cooler Not Installed
Diag
Page
Auto
Page
Stat
Page
Purge
Page
Contig
Page
