Operating the Autosampler 88
4
Figure 4-7 Purge and Compressibility Page
2. Calculate the purge time based on the flow rate and sample loop size. The time
must be sufficient to allow three volume changes of the autosampler. The
autosampler volume in Table 4-2
includes the inlet and outlet lines.
Ta b l e 4 - 3
lists sample purge times for the two sample loops at selected flow rates.
Table 4-2 Autosampler Volume
Sample Loop Autosampler Volume
Normal (200 µL) 836 µL
Auxiliary (2.4 mL) 3236 µL
PURGE
Edit: Purge and Compressibility
Purge Time (min) :
Compression Check?
Compression Pressure (psi) :
Pressure Decay Time (min) :
Compressible Volume ( 1) :
Pressure Change (psi)
Compressed Volume (psi)
Start
Purge
1.0
Yes
30
0.2
20
1.0
No
30
0.2
20
Main
Page
