Waters 717plus - 3.5 Priming the Needle Wash Pump

Startup and Configuration 64
3
3.5 Priming the Needle Wash Pump
To prime the needle wash pump:
1. Ensure that the needle wash supply line (green) is in the solvent bottle and the
waste line (yellow) is in an appropriate container.
2. To prime the needle wash, press the keys outlined in the flowchart below
(Figure 3-7
).
Figure 3-7 Priming the Needle Wash Pump
3. If, after 30 seconds, the solvent does not flow out of the waste line, press Start
NdlWash again.
TP01945
Menu Page
Menu: Diagnostic
Menu: User
Maintenance
Diag
Page
UserMaint
Page
Start
NdlWash
NdlWash
Page
Prime Needle
Wash Page
