Waters 717plus - 4.4 Loading the Carousel

Operating the Autosampler 84
4
Figure 4-4 Improper Needle Wash Solvent Location
3. With the 717plus Autosampler powered on, prime the needle wash pump (see
Section 3.5,
Priming the Needle Wash Pump).
4.4 Loading the Carousel
To load the carousel:
1. With the power on, open the sample compartment door. If the door sensor is
enabled (default condition), the autosampler releases the carousel.
STOP
Attention: Use only Waters
grey carousels. The Waters 717plus Autosampler does not
work with WISP™ white or brown carousels.
1
2
3
4
56
7
8
9
0
Home
Clear
Enter
CAROUSEL
Engage
Release
Needle Wash
Pump Location
Needle Wash
Solvent
