2.6 Changing the Hardware Configuration
This section covers:
• Removing the autosampler cover
• Installing the heater/cooler
• Installing the auxiliary sample loop
2.6.1 Removing/Replacing the 717plus Cover
Removing the Cover
To remove the autosampler cover (Figure 2-7):
1. Turn off the autosampler and disconnect the power cord.
2. Remove the syringe cover, and unscrew the cover retaining screw located to the
right of the magnetic latch.
3. Slide back the cover until it clears the posts on the rear panel.
4. Ensure that the red and blue fluid lines are free of the side cover slots.
5. Lift the cover up and back.
Table 2-5 RS-232 Parameters
Parameter Value
Baud rate 1200
Number of bits 8
Number of stop bits 1
Parity none
Caution: To avoid the possibility of electric shock, disconnect the autosampler power
cord before continuing this procedure.
STOP
Attention: Always replace the 717plus Autosampler cover to maintain RFI and EMI
shielding integrity.
Caution: To avoid the possibility of electric shock, do not remove the power supply cover.
The power supply does not contain user-serviceable components.
