Connecting Communication Cables 41
2
• High trigger > 3.0 V
• Protected to ±30 V
• Minimum pulse width: 30 milliseconds
• Maximum current: 5 milliamps
Output (Inject Start/Inject Stop) specifications are:
• Contact closure
• Maximum power 10 watts
• Maximum current: 0.5 amps at 20 V
• Maximum voltage: 40 Vdc at 0.25 amps
Making Cable Connections
Tools required:
• One small-blade screwdriver
• One electrical insulation stripping tool
• Signal cable from 717plus Autosampler Startup Kit
STOP
Attention: Do not connect two cables to the same autosampler terminal on the terminal
strip.
STOP
Attention: To meet the regulatory requirements of immunity from external electrical
disturbances that may affect the performance of this instrument, do not use cables longer
than 9.8 feet (3 meters) when you make connections to the screw-type barrier terminal
strips. In addition, ensure you always connect the shield of the cable to chassis ground at
one instrument only.
