Configuring the Autosampler 71
3
Inject Stop Pulse
5. The Inject Stop Pulse signal default pulse width is 0.5 seconds. Change the pulse
width if the instrument connected to the autosampler requires a different setting.
Setting IEEE-488 Address
To ensure that the autosampler is correctly identified when it is part of an IEEE-488
network, verify that the address is a unique number from 2 to 29. The default IEEE-488
address is set to 30.
Note: To use the Waters 717plus Autosampler in an IEEE-488 network, you must change
the address.
To change the address:
1. From the 717plus Main Menu, press Config Page.
2. From Configuration Page 1, press Next Cfg Page three times to view Page 4 of the
Configuration Pages.
3. On Configuration Page 4 (Figure 3-11
), highlight the desired IEEE Address field,
type the new address, and press Enter.
Note: The address must be unique to the system and must be a number between 2
and 29.
4. Press Reboot System to configure and store the new address.
Note: If the system controller is powered up, rescan the system to view the new
717plus Autosampler address. Refer to the system controller operator's manual for
details.
