Chapter 2 WCDMA Call Mode
WCDMA basics
WCDMA Options Version 6.20
81
WCDMA basics
In this section, you will find a short introduction to WCDMA system parameters.
We will look at the following aspects of a WCDMA system:
– WCDMA frequency bands
– Channel arrangement
– UARFCN
– UE power classes
WCDMA frequency bands The table below shows the specifications for the various WCDMA bands.
Channel arrangement The following sections provide information concerning channel spacing, channel
raster, channel number and UARFCN.
Channel spacing
The channel spacing is 5 MHz. However, to optimise performance in a specific
deployment scenario this value can be adjusted.
Channel raster
The channel raster is 200 kHz.
Channel number
The UARFCN (UTRA Absolute Radio Frequency Channel Number) designates the
carrier frequency.
Table 6 Technical System Parameters for UTRA FDD
Freq.
band
Uplink Downlink Duplex
I 1920 to 1980 MHz 2110 to 2170 MHz 190 MHz
II 1850 to 1910 MHz 1930 to 1990 MHz 80 MHz
III 1710 to 1785 MHz 1805 to 1880 MHz 95 MHz
IV 1710 to 1770 MHz 2110 to 2170 MHz 400 MHz
V 824 to 849 MHz 869 to 894 MHz 45 MHz
VI 830 to 840 MHz 875 to 885 MHz 45 MHz
