Chapter 4 Tools
Overview
106 WCDMA Options Version 6.20
Overview
This chapter shows you the functionality in the Tools section of the user inter-
face. The Tools menus can be found with a push on the Tools function
key.
The Tools menus can be divided into the following sections:
–Section “Configuration” on page 106 lets you view and change the instru-
ment configuration. This includes software updates and upgrades and inter-
face settings.
–Section “Utilities” on page 119 includes general functions such as a config-
urable power supply and current measurements.
–
Configuration
With the help of these menus, you may configure the interfaces of your 4400,
check whether a specific option has been installed or install options and new
software releases.
This section consists of the following parts:
– “Setup” – In this menu, you may select the language of the external
keyboard as well as some other settings.
– “I/O configuration” – This menu allows to set the GPIB address and the
external printer connected.
– “Options” – This menu provides an overview of the options installed on this
4400 and also allows to install further options.
– “Service and software update” – In this menu, you will find all details about
the software revisions installed in the various subsystems of your test set.
These details are very useful when discussing problems with the Willtek
product specialists. Furthermore, this menu allows to install new software
releases or to return to software releases installed previously.
Access to the
configuration menus
Push the TOOLS function key. The tool bar provides access to the configuration
menus with a push on the [Config] marker tab.
