Appendix A SCPI Command Reference
AFGenerator subsystem
WCDMA Options Version 6.20
447
AFGenerator subsystem
The AFG subsystem controls the accessible parameters of the audio generator.
Please note that all commands of this subsystem require the Audio Option to be
installed on your 4400.
:AFGenerator:STATe
:AFGenerator:MODE
:AFGenerator:OUTPut
Syntax
:AFGenerator:STATe <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF. Default is
OFF.
Description
Switches the AF (audio frequency) generator on or off.
Note: This command requires the Audio Option to be installed on your Willtek 4400.
Query
The query form of this command returns the current setting. A query will return a
string, containing one of the predefined expressions explained above.
Example
:AFGenerator:STATe ON
:AFG:STAT? Value returned: "ON".
Syntax
:AFGenerator:MODE <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: SINGle|REPLay.
Default is SINGle.
Description
This command sets the AF generator either to SINGle tone generator mode or to
wave file REPLay generator.
Query
The query form of this command returns the current setting. A query will return a
string containing the short-form version of one of the predefined expressions
explained above.
Example
:AFGenerator:MODE REPLay
:AFG:MODE? Value returned: "REPL".
Syntax
:AFGenerator:OUTPut <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: AF|CODec. Default is
AF.
