Chapter 2 WCDMA Call Mode
WCDMA basics
82 WCDMA Options Version 6.20
The following two tables show the definitions of the UARFCN values.
UARFCN For each paired band the following UARFCN range is supported.
Table 7 UARFCN definition
Uplink N
u
= 5 * F
uplink
0.0 MHz ≤ F
uplink
≤ 3 276.6 MHz
where F
uplink
is the uplink
frequency in MHz.
Downlink N
d
= 5 * F
downlink
0.0 MHz ≤ F
downlink
≤
3 276.6 MHz where F
downlink
is
the downlink frequency in MHz.
Table 8 UARFCN definition (band II additional channels)
UARFCN Carrier frequency [MHz]
Uplink N
u
= 5 * (F
uplink
–
1850.1 MHz)
F
uplink
= 1852.5, 1857.5,
1862.5, 1867.5, 1872.5,
1877.5, 1882.5, 1887.5,
1892.5, 1897.5, 1902.5,
1907.5
Downlink N
d
= 5 * (F
downlink
–
1850.1 MHz)
F
downlink
= 1932.5,
1937.5, 1942.5, 1947.5,
1952.5, 1957.5, 1962.5,
1967.5, 1972.5, 1977.5,
1982.5, 1987.5
Table 9 UTRA Absolute Radio Frequency Channel Number
Operating
band
Uplink
UE transmit,
Node B receive
Downlink
UE receive,
Node B transmit
I 9 612 to 9 888 10 562 to 10 838
II 9 262 to 9 538
and
12, 37, 62, 87, 112, 137, 162,
187, 212, 237, 262, 287
9 662 to 9 938
and
412, 437, 462, 487, 512,
537, 562, 587, 612, 637,
662, 687
III 8562 to 8913 9037 to 9388
IV 4162 to 4188 and 812, 837 4387 to 4413 and 1037,
1062
