Chapter 7 SCPI
The communication-related subsystems
WCDMA Options Version 6.20
233
Signaling operation register group
This group of registers is 16 bits wide. Its main task is to deal with events related
to the signaling status. The signaling operations depend on the system option
and the contents of the signaling operation register group are detailed in the
appendix.
The Result bit of this group of registers is forwarded to bit 8 of the general oper-
ation register group.
Measuring operation register group
This group of registers is 16 bits wide. Its main task is to deal with events related
to the measurement status.
The Result bit of this group of registers is forwarded to bit 9 of the general oper-
ation register group.
10 1024 Not in use.
11 2048 Not in use.
12 4096 Not in use.
13 8192 Instrument.
14 16384 Not in use.
15 32768 Not in use.
Bit Decimal Meaning
0 1 Set while RFTX measurements are in progress.
1 2 Set while RFRX (BER) measurements are in
progress.
2 4 Set while RFSPectrum measurements are in
progress.
3 8 Set while audio measurements are in progress.
4 16 Not in use.
532 Not in use.
6 64 Not in use.
7128 Not in use.
8 256 Not in use.
9512 Not in use.
10 1024 Not in use.
11 2048 Not in use.
12 4096 Not in use.
13 8192 Not in use.
14 16384 Not in use.
15 32768 Not in use.
