Appendix A SCPI Command Reference
STATus subsystem
WCDMA Options Version 6.20
281
:STATus:OPERation:SIGNalling:WCDMa:ENABLe
:STAT:OPERation:SIGNalling:WCDMa:PTRansition
Description
This command reads out the current contents of the signaling operation condition
register. This register reflects the current state of Willtek 4400 in terms of signaling
and will be updated continuously.
Note: This register is non-destructive. This means that it will keep its contents after
any query.
Query
There is only a query form of this command available. The query will return a string
containing one integer. The integer will express all bits set in the 16 bit signaling
operation condition register.
Note: For further details regarding the basic functions of the STATus subsystem,
please refer to section Understanding the STATus Subsystem.
Example
:STATus:OPERation:SIGNalling:WCDMa:CONDition?
Value returned in this example: "512".
This means that bit 9 has been set. Bit 9 will be reset as soon as the change of the call
channel has been completed. For details on return data (bits and decimals and their
meaning) refer to section “Signaling operation register group” on page 260.
Syntax
:STATus:OPERation:SIGNalling:WCDMa:ENABLe <int1>
Parameters
int1
is an integer. The minimum value for int1 is 0, the maximum value is
32767
. The value default is 0.
Description
This command sets the enable filter of the signaling operation register group. This
mask will be ANDed with the signaling operation event register and thus decide what
kind of events will be forwarded to bit 8 of the general operation register group
.
Query
There is no query form of this command available.
Example
:STATus:OPERation:SIGNalling:WCDMa:ENABle 16
This means that any setting of bit 4 of the signaling operation event register will rise
bit 8 of the general operation condition register. For details on return data (bits and
decimals and their meaning) refer to section “Signaling operation register group” on
page 260.
Syntax
:STAT:OPERation:SIGNalling:WCDMa:PTRansition <int1>
Parameters
int1
is an integer. The minimum value for int1 is 0, the maximum value is
32767
. The value default is 32767.
Description
Sets the PTR mask of the signaling operation register group. This mask will be ANDed
with the up to 15 bits of the PTR filter of the signaling operation condition register to
allow a positive transition of any bit (i.e. a transition from logic '0' to '1') to reach the
signaling operation event register.
Note The default of this mask is 32767 - that means that the mask will allow any
positive transition of the lower 15 bits of the condition-type register to reach the
event-type register.
Query
There is no query form of this command available.
Example
:STATus:OPERation:SIGNalling:WCDMa:PTRansition 0
This means that none of the positive transitions of the condition-type register will be
forwarded to the event-type register. For details on return data (bits and decimals
and their meaning) refer to section “Signaling operation register group” on page 260.
