Appendix A SCPI Command Reference
STATus subsystem
WCDMA Options Version 6.20
283
:STATus:OPERation:MEASuring:ENABLe
:STAT:OPERation:MEASuring:PTRansition
Description
This command reads out the current contents of the measuring operation condition
register. This register reflects the current state of the Willtek 4400 in terms of mea-
surements and will be updated continuously.
Note: This register is nondestructive. This means that it will keep its contents after
any query.
Query
There is only a query form of this command available. The query will return a string,
containing one integer. The integer will express all bits set in the 16 bit measuring
operation condition register.
Notes
– For further details regarding the basic functions of the STATus subsystem, please
refer to section “Understanding the STATus subsystem” on page 229.
– Bits 4 to 15 (the MSB) of this register are not used. Therefore, the maximum value
returned will be "7".
Example
:STATus:OPERation:MEASuring:CONDition?
Value returned: "1".
This means that bit 0 has been set and that there is an RFTX measurement currently
in progress. This bit will be reset as soon as the RFTX measurements have been com-
pleted.
Syntax
:STATus:OPERation:MEASuring:ENABLe <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 0.
Description
This command sets the enable filter of the “Measuring operation register group”. This
mask will be ANDed with the measuring operation event register and thus decide
what kind of events will be forwarded to bit 9 of the “General operation register
group”.
Query
There is no query form of this command available.
Example
:STATus:OPERation:MEASuring:ENABle 4
This means that any setting of bit 2 (RF spectrum) of the measuring operation event
register will rise bit 9 of the general operation condition register.
Syntax
:STAT:OPERation:MEASuring:PTRansition <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 32767.
Description
Sets the PTR mask of the “Measuring operation register group”. This mask will be
ANDed with the up to 16 bits of the PTR filter of the measuring operation condition
register to allow a positive transition of any bit (i.e. a transition from logic '0' to '1')
to reach the measuring operation event register.
Note: The default of this mask is 32767 – that means that the mask will allow any
positive transition of the lower 15 bits of the condition-type register to reach the
event-type register.
Query
There is no query form of this command available.
