Appendix A SCPI Command Reference
STATus subsystem
288 WCDMA Options Version 6.20
:STATus:QUEStionable:RF:PTRansition
:STATus:QUEStionable:RF:NTRansition
:STATus:QUEStionable:SYNChron[:EVENt]?
Query
There is no query form of this command available.
Example
:STATus:QUEStionable:RF:ENABle 15
This means that any setting of one of the lower four bits of the RF questionable sta-
tus event register will rise bit 9 of the general questionable status condition register.
Syntax
:STATus:QUEStionable:RF:PTRansition <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 32767.
Description
Sets the PTR mask of the “RF questionable status register group”. This mask will be
ANDed with the up to 16 bits of the PTR filter of the RF questionable status condi-
tion register to allow a positive transition of any bit (i.e. a transition from logic '0' to
'1') to reach the RF questionable status event register.
Note: The default of this mask is 32767 – that means that the mask will allow any
positive transition of the lower 15 bits of the condition-type register to reach the
event-type register of this group.
Query
There is no query form of this command available.
Example
:STATus:QUEStionable:RF:PTRansition 0
This means that none of the positive transitions of the condition-type register will be
forwarded to the event-type register.
Syntax
:STATus:QUEStionable:RF:NTRansition <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 0.
Description
Sets the NTR mask of the “RF questionable status register group”. This mask will be
ANDed with the up to 16 bits of the NTR filter of the RF questionable status condi-
tion register to allow a negative transition of any bit (i.e. a transition from logic '1' to
'0') to reach the RF questionable status event register.
Note: The default of this mask is 0 – that means that the mask will not allow any
negative transition of the 16 bits of the condition-type register to reach the event-
type register of this group.
Query
There is no query form of this command available.
Example
:STATus:QUEStionable:RF:NTRansition 0
This means that none of the negative transitions of the condition-type register will be
forwarded to the event-type register.
Syntax
:STATus:QUEStionable:SYNChron[:EVENt]?
Parameters
There are no parameters.
