Appendix A SCPI Command Reference
STATus subsystem
290 WCDMA Options Version 6.20
:STATus:QUEStionable:SYNChron:ENABLe
:STAT:QUES:SYNChron:PTRansition
:STAT:QUES:SYNChron:NTRansition
Syntax
:STATus:QUEStionable:SYNChron:ENABLe <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 0.
Description
This command sets the Enable filter of the “SYNChronization questionable status reg-
ister group”. This mask will be ANDed with the synchronization questionable status
event register and thus decide what kind of events will be forwarded to bit 10 of the
“General questionable status register group”.
Query
There is no query form of this command available.
Example
:STATus:QUEStionable:SYNChron:ENABle 3
This means that any setting of one of the lower two bits of the synchronization ques-
tionable status event register will rise bit 10 of the general questionable status condi-
tion register.
Syntax
:STAT:QUES:SYNChron:PTRansition <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 32767.
Description
Sets the PTR mask of the “SYNChronization questionable status register group”. This
mask will be ANDed with the up to 16 bits of the PTR filter of the synchronization
questionable status condition register to allow a positive transition of any bit (i.e. a
transition from logic '0' to '1') to reach the synchronization questionable status event
register.
Note: The default of this mask is 32767 – that means that the mask will allow any
positive transition of the lower 15 bits of the condition-type register to reach the
event-type register of this group.
Query
There is no query form of this command available.
Example
:STAT:QUES:SYNChron:PTRansition 0
This means that none of the positive transitions of the synchronization questionable
status condition register will be forwarded to the event-type register.
Syntax
:STAT:QUES:SYNChron:NTRansition <int1>
Parameters
int1 is an integer. The minimum value for int1 is 0, the maximum value is
32767. The default value is 0.
Description
Sets the NTR mask of the “SYNChronization questionable status register group”. This
mask will be ANDed with the up to 16 bits of the NTR filter of the synchronization
questionable status condition register to allow a reset (negative transition) of any bit
(i.e. a transition from logic '1' to '0') to reach the corresponding event-type register.
Note: The default of this mask is 0 – that means that the mask will not allow any
negative transition of the 16 bits of the condition-type register to reach the corre-
sponding event-type register.
Query
There is no query form of this command available.
