Appendix A SCPI Command Reference
CONFigure subsystem
WCDMA Options Version 6.20
301
:CONF:WCDMa:POWMeasure:ULTArget
:CONF:WCDMa:POWMeasure:ULTArget:FORCe
:CONFigure:WCDMa:NB:LEVel
:CONFigure:WCDMa:NB:LEVel:RELative
Query
The query form of this command returns the current setting for
PredefExp.
Example
:CONF:WCDMA:POWM:RRCF OFF
:CONF:WCDMA:POWM:RRCF?
Value returned in this example:
OFF.
Syntax
:CONF:WCDMa:POWMeasure:ULTArget <Real1>
Parameters
Real1 is a floating point real number. The minimum value is -50, the maximum
value 33
. The minimum resolution is 0.1. The default value is -50.
Description
This command will set the UL Target Power.
Query
This query gets the UL Target Power.
Example
:CONF:WCDM:POWM:ULTA -10.0:CONF:WCDM:POWM:ULTA?
Value returned in this example: -10.0
Syntax
:CONF:WCDMa:POWMeasure:ULTArget:FORCe
<PredefExp>
Parameters
PredefExp is one of the following predefined expressions:
NONe|MINimum|MAXimum
. Default is NONe.
Description
This command forces the UE to transmit with minimum or maximum power. If set to
NONe the UE is set to transmit with the value set by command:
CONF:WCDM:POWM:ULTA.
Query
The query form of this command returns the current setting for PredefExp
.
Example
:CONF:WCDM:POWM:ULTA:FORC MAX
:CONF:WCDM:POWM:ULTA:FORC?
Value returned in this example: MAX
.
Syntax
:CONFigure:WCDMa:NB:LEVel <Real1>
Parameters
Real1
is a floating point real number. The minimum value is -120, the maximum
value -20. The minimum resolution is 0.1. The default value is -40.
Description
This command sets the RF output level of the 4400. The value specified for real1 is
the power output level in dBm.
Query
The query form of this command will return the current setting of the Willtek 4400.
Example
:CONF:WCDMA:NB:LEV -38.0
:CONF:WCDMA:NB:LEV?
Value returned in this example: -38.0
.
Syntax
:CONFigure:WCDMa:NB:LEVel:RELative <PredefExp>
