Appendix A SCPI Command Reference
CONFigure subsystem
316 WCDMA Options Version 6.20
:CONFigure:COUPloss:INFormation?
:CONFigure:WCDMa:COUPloss:DATA
Query
The query form of this command will return the name of the currently loaded cou-
pling loss description file. The string delivered will contain the full file name.
Example
:CONFigure:COUPloss:NAME "m7389.cpl"
:CONF:COUP:NAME?
Value returned in this example: "m7389.cpl"
Syntax
:CONFigure:COUPloss:INFormation?
Parameters
There are no parameters.
Description
This command is used to read out the comments saved with the coupling loss
description file currently loaded.
For more details, please refer to section Coupling Loss.
Note There is only a query form of this command available.
Query
The query form of this command will return the comments saved with the coupling
loss description. The string delivered back will contain a maximum of 255 characters.
Example
:CONFigure:COUPloss:INFormation?
Value returned in this example: "Motorola P7389 with Antenna Cou-
pler"
Syntax
:CONFigure:WCDMa:COUPloss:DATA <string1>
,<realf1>,<reala1>,<realf2>,<reala2> [,realf3]
[,reala3] [,realf4] [,reala4] [,realf5] [,reala5]
[,realf6] [,reala6] [,realf7] [,reala7] [,realf8]
[,reala8] [,realf9] [,reala9] [,realf10] [,reala10]
[,realf11] [,reala11] [,realf12] [,reala12] [,realf13]
[,reala13] [,realf14] [,reala14] [,realf15] [,reala15]
[,realf16] [,reala16] [,realf17] [,reala17] [,realf18]
[,reala18] [,realf19] [,reala19] [,realf20] [,reala20]
Parameters
string1 is a comment line related to the coupling loss data. The maximum length
of string1 is 255 characters.
realfx are floating point real numbers, giving frequencies in MHz while realax
are floating point real numbers, giving the corresponding coupling loss in dB.
All realfx have to be within two frequency ranges. The lower frequency range is
from 800.0 MHz to 1000.0 MHz, the higher frequency range is from
1700.0 MHz to 2000.0 MHz.
The minimum resolution for all realfx values is 10 Hz (0.00001 MHz).
The default value for all realfx is 800.0 MHz.
The minimum value for all realax is -5.0 dB.
The maximum value for all realax is 40.0 dB.
The minimum resolution for all realax is 0.01 dB.
The default value for all realax is 0.0.
Notes
– Please keep in mind that at least one pair of values for a frequency and the
related attenuation must be specified per frequency range, while all other 18
pairs are optional.
– All realax
values are interpreted as an attenuation level in dB. As a conse-
quence, negative values mean an amplification of the input signal
.
