Appendix A SCPI Command Reference
MEASure subsystem
338 WCDMA Options Version 6.20
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:ERMS
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:EPEAk
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:MRMS
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:MPEAk
Example
:MEAS:WCDM:RFTX:MODQ:ALL?
In this case, all relevant RFTX measurements will be performed in a sequence, e.g.
21.624,72.8,15.335,72.736,6.738,27.512,-6.378,0.961,-
28.251,-43.743
.
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:ERMS
Parameters
There are no parameters.
Description
Starts a continuous RMS vector error magnitude measurement.
Query
The query form of this command will return a floating point value; the unit is percent.
Example
:MEAS:WCDM:RFTX:MODQ:ERMS?
Returns the measured EVM RMS vector error, e.g. 21.624
.
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:EPEAk
Parameters
There are no parameters.
Description
Starts a continuous peak vector error magnitude measurement.
Query
The query form of this command will return a floating point value in percent.
Example
:MEAS:WCDM:RFTX:MODQ:EPEA?
Returns the measured EVM peak vector error, e.g.
72.8.
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:MRMS
Parameters
There are no parameters.
Description
Starts a continuous RMS magnitude measurement.
Query
The query form of this command will return a floating point value; the unit is percent.
Example
:MEAS:WCDM:RFTX:MODQ:MRMS?
Returns the measured Magnitude RMS vector error, e.g. 15.335
.
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX:MODQuality:MPEAk
Parameters
There are no parameters.
Description
Starts a continuous peak magnitude measurement.
Query
The query form of this command will return a floating point value in percent.
