Appendix A SCPI Command Reference
CALCulate Subsystem
382 WCDMA Options Version 6.20
:CALCulate:AFANalyser
:ACVoltage:PPEAk:LIMit[:FAIL]?
:CALCulate:AFANalyser:ACVoltage:PEAKp:LIMit:STATe
:CALCulate:AFANalyser
:ACVoltage:PEAKp:LIMit:UPPer[:DATA]
Query
The query form of this command is not supported.
Example
:CALC:AFAN:ALL:LIM:LOW 1,1,0,400,0,25
Sets the lower limits for the audio measurements.
Syntax
:CALCulate:AFANalyser
:ACVoltage:PPEAk:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers one boolean number, indicating whether the user-definable
limits of the peak-to-peak measurement of the AC voltage applied to the audio ana-
lyzer were violated by a measurement result value or not.
A 0 means that the measurement result value is within the limits set, while a 1 indi-
cates that at least one measurement result value did violate at least one of the limits.
The limits can be set using the commands described below.
Example
:MEAS:ARRay:AFAN:ACV:PPEA 10
:CALC:AFAN:ACV:PPEA:LIM?
String returned: "1"
This string delivered back indicates that at least one measurement result value did
violate the limits of the peak-to-peak AC measurement.
Syntax
:CALCulate:AFANalyser:ACVoltage:PEAKp:LIMit:STATe
<PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF. Default is ON.
Description
This command switches the check of the measurement result values of the
MEAS:AFAN:ACV:PEAK measurement against their user-definable limits either
on or off.
Query
There is no query form of this command available.
Example
:CALC:AFAN:ACV:PEAK:LIM:STAT ON
Switches the limit check of the peak-to-peak AC voltage measurement on.
Syntax
:CALCulate:AFANalyser
:ACVoltage:PEAKp:LIMit:UPPer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maximum is
30.0. The minimum resolution possible is 0.0001, the default value is 5.0.
Description
Sets the upper limit for the peak-to-peak measurement of the AC voltage applied to
the audio analyzer. The physical dimension of the number stated is V(pp).
Query
The query form of this command is not available.
