Appendix A SCPI Command Reference
CALCulate Subsystem
388 WCDMA Options Version 6.20
:CALCulate:AFANalyser
:DISTortion:LIMit:UPPer[:DATA]
:CALCulate:AFANalyser
:DISTortion:LIMit:LOWer[:DATA]
:CALCulate:AFANalyser
:SINad:LIMit[:FAIL]?
Description
This command switches the check of the measurement result values of the
MEAS:AFAN:DIST measurement against their user-definable limits either on or
off.
Query
There is no query form of this command available.
Example
:CALC:AFAN:DIST:LIM:STAT ON
Switches the limit check of the distortion measurement on.
Syntax
:CALCulate:AFANalyser
:DISTortion:LIMit:UPPer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maximum is
100.0. The minimum resolution possible is 0.1, the default value is 5.0.
Description
Sets the upper limit for the distortion measurement. The physical dimension of the
number stated is percent (the relation of the AC voltage measured for the third har-
monic of a 1 kHz sine wave in relation to the AC voltage measured for the nominal
frequency).
Query
The query form of this command is not available.
Example
:CALC:AFAN:DIST:LIM:UPP 4.5
Sets the upper limit of the distortion measurement to 4.5%.
Syntax
:CALCulate:AFANalyser
:DISTortion:LIMit:LOWer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maximum is
100.0. The minimum resolution possible is 0.1, the default value is 0.0.
Description
Sets the lower limit for the distortion measurement. The physical dimension of the
number stated is percent (the relation of the AC voltage measured for the third har-
monic of a 1 kHz sine wave in relation to the AC voltage measured for the nominal
frequency).
Query
The query form of this command is not available.
Example
:CALC:AFAN:DIST:LIM:LOW 0.0
Sets the lower limit of the distortion measurement to 0%.
Syntax
:CALCulate:AFANalyser
:SINad:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
