Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
391
:CALCulate:AFSPectrum:TEMPlate:LIMit:STORe
:CALCulate:AFSPectrum:TEMPlate:LIMit:COMMent
Description
This command loads the audio template description file. Please note that the data
contained in the file need to be activated (using the
CALC:AFSP:TEMP:LIM:STAT ON command described above) before the tem-
plate will have any effect on the measurement results.
Query
There is no query form of this command available.
Example
:CALC:AFSP:LIM:LOAD "example.lmt"
Loads the audio spectrum template file example.lmt which resides in the
/rapid/audiolmt directory.
Syntax
:CALCulate:AFSPectrum:TEMPlate:LIMit:STORe <string1>
Parameters
string1 is a string giving the name of the file in which the current audio limits are
to be saved.
The maximum length of string1 is 50 characters.
Description
This command saves the current audio template in a file. The template can be defined
by the FREQ, UPPer, LOWer and COMMent comments.
Query
There is no query form of this command available.
Example
:CALC:AFSP:LIM:STORe "example.lmt"
Stores the currently defined audio spectrum template in the file example.lmt in the
/rapid/audiolmt directory. If a file of this name already exists, it will be overwritten.
Syntax
:CALCulate:AFSPectrum:TEMPlate:LIMit:COMMent <string1>
Parameters
string1 is a comment line related to the coupling loss data. The maximum length
of string1 is 80 characters.
Description
Defines a comment line for storage in the audio template file and for display in the
Comment line field on the Limits screen.
Note: The comment can be saved with the STORe command, together with the other
template parameters.
Query
There is no query form of this command available.
Example
:CALC:AFSP:LIM:COMM "Audio template for Siemens S35"
