Appendix A SCPI Command Reference
CALCulate Subsystem
400 WCDMA Options Version 6.20
:CALCulate:EGPRs:RFTX:ALL:LIMit[:FAIL]?
:CALCulate:EGPRs:RFTX:ALL:LIMit:STATe
Description
Sets the lower limit for the peak current consumption measurement. The physical
dimension of the number stated is mA.
Query
There is no query form of this command available.
Example
:CALC:PSUP:PCUR:LIM:LOW 10
Sets the lower limit of the peak current consumption measurement to 10 mA.
Syntax
:CALCulate:EGPRs:RFTX:ALL:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers 8 boolean numbers in a string, separated by commas. These
numbers indicate, whether the single measurement results of the
:MEAS:EGPRs[:ARRay]:RFTX:ALL measurement did violate their test limits.
The position of the boolean number within the string returned indicates the result of
the limit check for the following measurements:
1. error vector magnitude rms-averaged measurement,
2. maximum error vector magnitude measurement,
3. error vector magnitude that is not exceede by 95% of the symbols of a burst mea-
surement,
4. error vector magnitude origin offset measurement,
5. measurement of the mobile's frequency error,
6. measurement of the burst lenght,
7. timing error measurement,
8. measurement of the mobile's RF output power level.
Example
:MEAS:EGPR:RFTX:ALL
:CALC:EGPR:RFTX:ALL:LIM?
String returned in this example:"0,0,0,0,0,0,0,1"
1 on position 8 indicates that the mobile's RF power level violated its test limits.
Syntax
:CALCulate:EGPRs:RFTX:ALL:LIMit:STATe <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF. Default is ON.
Description
This command switches the limit check of the relevant EGPRS RF TX measure-
ment result values of the MEAS:EGPRs:RFTX:ALL measurement against their
user-definable limits either ON or OFF.
Query
There is no query form of this command available.
Example
:CALC:EGPR:RFTX:ALL:LIM:STAT OFF
Switches the limit check for the most relevant EGPRS RF TX measurements off.
