Appendix A SCPI Command Reference
CALCulate Subsystem
410 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:CPOWer:LIMit:UPPer:[DATA]
:CALCulate:WCDMa:RFTX:CPOWer:LIMit:LOWer:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:ALL:LIMit[:FAIL]
:CALCulate:WCDMa:RFTX:MODQuality:ALL:LIMit:STATe
Syntax
:CALCulate:WCDMa:RFTX:CPOWer:LIMit:UPPer:[DATA] <real>
Parameters
real is a floating point real number. Its minimum value is -120.0, the maximum
is 50.0, the resolution is 0.1 and the default is 34.0.
Description
Sets the upper limit for the mobile's RF output channel power. The physical dimension
of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:CPOW:LIM:UPP 2.5
:CALC:WCDM:RFTX:CPOW:LIM:UPP?
Returns 2.5.
Syntax
:CALCulate:WCDMa:RFTX:CPOWer:LIMit:LOWer:[DATA] <real>
Parameters
real is a floating point real number. Its minimum value is -120.0, the maximum
is 50.0, the resolution is 0.1 and the default is -60.0.
Description
Sets the lower limit for the mobile's RF output channel power. The physical dimension
of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:CPOW:LIM:LOW -2.5
:CALC:WCDM:RFTX:CPOW:LIM:LOW?
Returns -2.5.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:ALL:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the
:MEAS:WCDMA:ARR:RFTX:MODQ:ALL measurement violated its limits.
Example
:MEAS:WCDMA:ARR:RFTX:MODQ:ALL 20
:CALC:WCDM:RFTX:MODQ:ALL:LIM?
The query returns 1 if any of the measurement results was out of limits, or 0 if none
of the results was out of limits.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:ALL:LIMit:STATe
<PredefExp>
Parameters
PredefExp may take on one of the following predefined expressions: ON|OFF.
The default is ON.
