Appendix A SCPI Command Reference
CALCulate Subsystem
434 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFRX:BER:LIMit:UPPer:[DATA]
:CALCulate:WCDMa:RFRX:BER:LIMit:LOWer:[DATA]
:CALCulate:WCDMa:RFRX:BLER:LIMit[:FAIL]
:CALCulate:WCDMa:RFRX:BLER:LIMit:STATe
Syntax
:CALCulate:WCDMa:RFRX:BER:LIMit:UPPer:[DATA] <real>
Parameters
real is a floating point real number. Its minimum value is 0.0, the maximum is
50.0, the resolution is 0.1 and the default is 0.1.
Description
Sets the upper limit for the mobile's Bit Error Rate. The physical dimension of the
number is stated as a percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFRX:BER:LIM:UPP 2.5
:CALC:WCDM:RFRX:BER:LIM:UPP?
Returns 2.5.
Syntax
:CALCulate:WCDMa:RFRX:BER:LIMit:LOWer:[DATA] <real>
Parameters
real is a floating point real number. Its minimum value is 0.0, the maximum is
1.0, the resolution is 0.1 and the default is 0.0.
Description
Sets the lower limit for the mobile's Bit Error Rate. The physical dimension of the
number is stated as a percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFRX:BER:LIM:LOW 0.0
:CALC:WCDM:RFRX:BER:LIM:LOW?
Returns 0.0.
Syntax
:CALCulate:WCDMa:RFRX:BLER:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the
:MEAS:WCDMA:ARR:RFRX:BLER measurement violated the defined limits.
Example
:MEAS:WCDMA:ARR:RFRX:BLER 20
:CALC:WCDM:RFRX:BLER:LIM?
The query returns 1 if any of the 20 measurement results was out of limits, or 0 if
none of the results was out of limits.
Syntax
:CALCulate:WCDMa:RFRX:BLER:LIMit:STATe <PredefExp>
Parameters
PredefExp can take on one of the following values: ON|OFF. The default is ON.
Description
This command switches the check of the measurement result values of the Bler mea-
surement against their user-definable limits either ON or OFF.
