Appendix A SCPI Command Reference
MS Power Supply subsystem
456 WCDMA Options Version 6.20
Description
Selects the range of the maximum current the mobile under test is expected to draw.
For a maximum current of up to 400 mA, the MA400 setting can be used. If the
mobile will not draw more than 400 mA, the MA400 setting is appropriate.
In case the maximum power requirement of the mobile is unknown, setting A4 (the
default setting) is recommended as it will allow the mobile to draw a maximum cur-
rent of 4 A.
Please note that this command needs both the power supply option and the current
measurement option to be installed on your Willtek 4400. Details regarding these
options can be found in section “Accessories and options” on page 29.
Query
The query form of this command returns the current setting. A query will return a
string, containing one of the predefined expressions explained above.
Example
:PSUPply:MEASure:CMAX MA400
:PSUP:MEAS:CMAX? Value returned: "MA400".
