Phaser 3600 Printer Service Manual 7-11
Service Parts Disassembly
8. Disconnect the Control Panel wiring harness (CN17) from the Main
Board.
Replacement Note
Note the position of the wiring harness and ferrite coil for reassembly.
s3600-010
