Phaser 3600 Printer Service Manual 1-5
General Information
Control Panel
The Control Panel has three components:
■ Multi-colored Light Emitting Diode (LED) light
■ Alphanumeric display
■ Six-button cluster
Menu Map
The Menu Map is a visual representation of the Control Panel settings and
information pages. All Menu Map settings are documented in the User Guide.
Error and Warning Messages
When there is a problem with the printer, the Control Panel LED (3) blinks red
for an error and a warning. An error or warning message is displayed in the
Alphanumeric Display (5).
Control Panel Buttons
Button Function
Return Returns to the prior higher level menu structure, if
avai
l
able.
CANCEL Terminates the current action.
MENU Cycles through all of the top level menu items.
UP Scrolls up one menu item within a menu list. If you
con
t
inually press this control, the menu items will ‘wrap’.
DOWN Scrolls up one menu item within a menu list. If you
cont
inually press this control, the menu items will ‘wrap’.
OK Executes the highlighted menu item.

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
