Phaser 3600 Printer Service Manual 7-67
Service Parts Disassembly
Pressure Roller (PL 1.4.66) and Bushing (PL 1.4.50)
Warning
Be sure you turn off the Printer and let the Fuser cool for 5 minutes
1. Remove the Fuser Assembly from the Printer (page 7-54).
2. Remove two screws from the Fuser assembly (see inset below).
s3600-114
