Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 3-19
Error Messages
Close Fuser Door
Close Top Cover
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser Assembly, PL1.4.1
■ Main Board, PL1.1.19
■ Switched Mode Power Supply
(SMPS), PL1.1.29.2
■ “LSU and Main Motor to Main Board
Wiring Diagram” on page 9-16
■ “Map 2- Main Board” on page 9-5
■ “Map 3- SMPS Board” on page 9-6
Step Action and Questions Yes No
1. Visually inspect the fuser door
close tab
for damage.
Is the tab broken?
Replace the Fuser
(page 7-54) then
go to Step 3.
Go to Step 2.
2. Is the sensor and actuator on the
Fuser o
perating correctly.
Replace the Main
Board
(page 7-39).
Replace the Fuser
(page 7-54) then
go to Step 3.
3 Is the Printer operational? Complete Replace the SMPS
(page 7-76).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Top Cover, PL1.4.1
■ Main Board, PL1.1.19
■ “Map 2- Main Board” on page 9-5
Troubleshooting Procedure Table
Step Action and Questions Yes No
1. Visually inspect the top cover and the
top cover actu
ator.
Is the Top Cover or actuator
damage
d?
Replace the Top
Cover
(page 7-10).
Go to
Step 2.
2. Use diagnostics to test the Cover
Open Board.
Does th
e Cover Open board function
prop
erly?
Replace the Main
Bo
ar
d
(page 7-39).
Replace the
Cover Open
Board
(page 7-74).

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
