7-2 Phaser 3600 Printer Service Manual
Service Parts Disassembly
Service Overview
This section contains the removal and replacement procedures for selected
parts of the printer according to the Service Parts List. Not all Replacement
Procedures are included in this Service Manual. In most cases, to reinstall a
part, simply reverse the Removal Procedure shown. In some instances, the
Replacement Procedure is included, because it may contain special steps.
For specific assemblies and parts, see ”Parts List” on page 8-1.
General Notes on Disassembly
Preparation
Before you begin any Removal and Replacement Procedure:
1. Switch OFF the printer power and disconnect the power cord from the
wall outlet.
2. Remove the Print Cartridge and protect it from exposure to light by
covering it with a light proof bag or by placing it in a light-tight container.
3. Disconnect all computer interface cables from the printer.
4. Wear an electrostatic discharge wrist strap to help prevent damage to the
sensitive electronics of the printer circuit boards.
Warning
Remove the Fuser Assembly or wait at least 5 minutes after you have
switched OFF printer power for the Fuser to cool before you work on or
around the Fuser.
