Xerox Phaser 3600 Service Manual

Phaser 3600Printer Service Manual 9-13
Plug/Jack and Wiring Diagrams
HVPS/SMPS to Main Board Wiring Diagram
Main Board
s3600-024
CN19
CON4
CON1
LVPS (SMPS)
HVPS
14
13
12
11
10
1
2
3
4
5
6
7
8
9
9
8
7
6
5
4
3
2
1
10
11
12
13
14
CN22
DEV_AC_PWM
DEV_AC_CON
DEV_VDC_PWM
FUSER_BIAS_PWM
MHV_PWM
MHV_READ
THV_PWM
THV_READ
nTHV_EN
VCC
VCC
GND
GND
GND
GND
GND
GND
GND
FUSER_COVER
FUSER_ON
+24VDC
+24VDC
+24VDC
+24VDC
+24VDC
+3.3VDC
+3.3VDC
+3.3VDC
CON3
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
1
2
3
4
5
6
7
8
9
DEV_AC_Vpp
9
8
7
6
5
4
3
2
1
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
CON6
CN1
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
HOT
2
NEUTRAL
AC Inlet
CON5
1
+24VAC
+24VAC
2
3
NC
Jam Cover
Microswitch
CON2 FSR1
1
HOT
2
3
NEUTRAL
Fuser
+24VAC
+3.3VDC
HVPS
s3600-025
+3.3VDC
+3.3VDC
CN3
1
2
3
CN?
3
2
1
GND
P_FEED
+3.3VDC
Registration
Sensor
CN4
1
2
3
CN?
3
2
1
GND
P_MARGIN
+3.3VDC
Tray 1 Feed
Sensor
Tray
Empty
Sensor

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
