Xerox Phaser 3600 Service Manual

1-2 Phaser 3600 Printer Service Manual
General Information
Printer Configurations
Printer Options and Supplies
Print Features and Configurations
Features
Printer Configurations
3600_B 3600V_B 3600_N 3600V_N
Maximum Print Speed
Le
tter
40 ppm 40 ppm 40 ppm 40 ppm
Memory (Optional)
Up to 512 MB Optional if
th
e original DIMM is
replaced with 256MB RAM
DIMM and the second slot
has a 256MB RAM DIMM
64 MB 64 MB 128 MB 128 MB
PostScript and PCL Fonts Yes Yes Yes
Default Resolution
Maximum Resolution
600 x 600 dpi
1200 x 1200
dpi
600
x 600 dpi
1200 x 1200
dpi
500-Sheet Feeder (Tray 3) Optional Optional Optional Optional
Network Interface Not Optional Not Optional Standard Standard
Automatic 2-Sided Printing
(Separate Duplex
Unit)
Optional Optional Optional Standard
USB, Parallel Interface Yes Yes Yes Yes
Options and Supplies
Printer Option Item Part Number
Memory 64 MB additional RAM memory
128 MB additional RAM memory
256 MB additional RAM memory
097S03759
097S03760
097S03761
Optional Units Duplex Unit
500-Sheet Feeder
097S03387
097S03385
Cartridges Standard-Capacity Print Cartridge
(7,0
00 pages)
Hi
gh-Capacity Print Cartridge (14,000
pages)
Extra High-Capacity Print Cartridge
(20
,
000 pages)
Metered/Pagepack Print cartridge
(20,
000 pages)
106R01370
106R01371
106R01372
106R01369
Gear Lubricant Xerox lubricant Plastislip grease 043E00550

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
