Xerox Phaser 3600

7-58 Phaser 3600 Printer Service Manual
Service Parts Disassembly
Fuser Thermistor (PL 1.4.40)
Warning
Be sure you turn off the Printer and let the Fuser cool for 5 minutes
1. Remove the Fuser Assembly from the Printer (page 7-54).
2. Remove two screws from the Fuser assembly (see inset below).
s3600-114
