Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual xi
Manual Organization
The Phaser 3600 Printer Service Manual is the primary document used for
repairing, maintaining, and troubleshooting the printer. Use this manual as
your primary resource for understanding the operational characteristics of the
printer and all available options. This manual describes specifications, theory,
and the diagnosis and repair of problems occurring in the print engine and
attached options. Also included are detailed replacement procedures, parts
lists, and wiring diagrams.
The Phaser 3600 Printer Service Manual contains these chapters:
Introductory, Safety, and Regulatory Information: This section contains important
safety information and regulatory requirements.
Chapter 1 - General Information: This chapter contains an overview of the
printer’s operation, configuration, specifications, and consumables.
Chapter 2 - Theory of Operation: This chapter contains detailed functional
information on the printer components.
Chapter 3 - Error Messages: This chapter provides detailed troubleshooting
procedures for error messages generated by resident diagnostics.
Chapter 4 - General Troubleshooting: This chapter contains general information
on troubleshooting the printer. In addition, this chapter includes
troubleshooting methods for situations where error indicators are not
available.
Chapter 5 - Print-Quality Troubleshooting: This chapter focuses on techniques to
correct image quality problems associated with the printer output.
Chapter 6- Cleaning and Maintenance: This chapter provides periodic cleaning
procedures for the printer.
Chapter 7- Service Parts Disassembly:
This chapter contains removal
procedures for spare parts listed in the Parts List. A replacement procedure is
included when necessary.
Chapter 8- Parts List: Th
is chapter contains exploded views of the print engine
and optional Field Replaceable Units (FRUs), as well as part numbers for
orderable parts.
Chapter 9- Plug/Jack and Wiring Diagrams: This chapter contains the plug/jack
locations and the wiring diagrams for the printer.
Reference: This section provides a list of acronyms and abbreviations

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
