Xerox Phaser 3600 Service Manual

8-8 Phaser 3600 Printer Service Manual
Parts List
21.1 GEAR MP HOLDER CAM
21.2 GEAR MP PICK UP
21.3 SPRING ETC CAM MP
22 BEARING PICK UP
23 BRACKET P SHAFT MP
25 SOLENOID MAIN 121N01167
26 SOLENOID MP (Tray 1 (MPT) Pick Solenoid) 121N01102
27 RING E
28 SHIELD P SMPS
29 SMPS V1- 110V
SMPS V2- 220V
105N02144
105N02146
30 BAR P CROSS BOTTOM (Front Bottom Cross Bar)
31 FAN DC (Left Side Cooling Fan) 127N07569
32 STOPPER M FAN80
34 ELA UNIT DEVE (Print Cartridge)
7K Toner Cartridge
14K Toner Cartridge
106R01370
106R01371
35 ELA UNIT CASSETTE (Tray 2) 109R00756
36 ELA UNIT SCF (Optional Tray 3) 097N01673
37 ELA UNIT DUPLEX 097N01679
38 BRACKET P DUMMY CTRL
39 HVPS 105N02145
39.1 BRACKET NIC
39.2 PBA SUB (NIC BOARD)
40 STOPPER M NETWORK
41 40MM FAN 127N07568
PL 1.1 Main Assembly Parts List Table (continued)
ID N
o
. Name/Description Part Number

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
