Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-11
Parts List
PL 1.2 Cover Assembly Parts List Table
ID No. Name/Description Part Number
1 (1-X) AS UNIT COVER TOP 002N02411
1-1 COVER M TOP 002N02730
1-2 COVER M OPEN XRX 002N02729
1-3 PMO STACKER RX 002N02418
1-4 LEVER M STACKING 38 036N00030
1-5 STOPPER M HINGE OPEN
1-6 COVER M OP PANEL XRX
1-7 SHEET OVERLAY BUTTON
1-8 MEC BRUSH ANTISTATIC
1-9 PBA SUB PANEL B’D 140N63320
1-10 KEY M BUTTON XRX
1-11 KEY M CANCEL
1-12 CAP M LED XRX
1-13 WINDOW M LCD
2 COVER M LEFT 002N02413
3 COVER M RIGHT 002N02414
4 COVER M CONTROL BOX 002N02419
5 COVER M FRONT INNER 002N02415
6 MEA UNIT COVER REAR 002N02416
6.1 COVER M REAR
6.2 PMO STACKER REAR
6.3 ICT BRKT REAR COVER
6.4 GUIDE M EXIT
6.5 PMO STRIPE 001N00462
6.7 PEX ROLLER F/UP(2)
6.8 SPRING ETC SEPARATION
6.9 LABEL(P) JAM REMOVAL
6.10 FAN 127N07569
7 CO VER M FRAME EXIT 002N02417
8 COVER M DUMMY DUP (FILLER PANEL) 002N02420

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
