Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-25
Parts List
PL 2.1 Tray 2 Assembly Parts List Table
Item No. Description Part Number
0 ELA UNIT CASSETTE 109R00756
1 FRAME M CASSETTE
2 GUIDE M HANDLE
3 INDICATOR EMPTY
4 PLATE P KNOCK UP
5 SPRING PLAT K/UP
6 GEAR PINION
7 CAP M GUIDE SIDE L
8 GUIDE P SIDE L
9 GUIDE M SIDE LOCK
10 GUIDE P SIDE R
11 GUIDE M REAR
12 GUIDE P REAR PAPER
13 SPRING ETC GUIDE PAPER
14 GUIDE M LOCK
15 GUIDE M REAR
16 GUIDE M EXTENTION
17 BRACKET P EXTENTION
18 GUIDE M PAPER
19 HOLDER M PAD HOUSING
20 MEA UNIT HOLDER PAD 019N00947
20-1 HOLDER M PAD
20-2 SHEET HOLDER PAD R2
20-3 RPR FRICTION PAD
20-4 IPR PLATE PAD
21 SPRING EXIT ROLL FD
25 PMO LOCKER PLATE
26 SPRING LOCKER PLATE
27 GUIDE M PAPER SIZE

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99
