Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-27
Parts List
PL 2.2 Tray 3 Cassette Parts List Table
Item No. Description Part Number
0 ELA UNIT SCF (Tray 3, 500-sheet feeder) 050N00543
1 FRAME M SCF
2 COVER M RIGHT SCF
3 COVER M LEFT SCF
4 COVER M DUMMY SCF
5 PBA SCF 140N63300
6 CBF HARNESS OPE
8 BUSH CABLE
9 CBF HARNESS SCF INTERFACE 152N11714
10 SOLENOID MAIN
11 ELA UNIT MOTOR SCF 127N07570
11-1 BRACKET P SCF MOTOR
11-2 MOTOR STEP 7.5 DEG
11-3 GEAR M SCF RDCN RETARD
11-4 GEAR M SCF RDCN FEED
11-5 GEAR M SCF RDCN PICK UP
12 CBF HARNESS OPE
13 IPR GROUND SPRING FEED
14 PMO BEARING SHAFT
15 MEP CLUTCH FEED SCF
16 RING E
17 SHAFT M COUPLING RETARD S
18 SHAFT M GEAR RETARD
19 GEAR REGI Z25
20 BAR P CROSS BOTTOM
21 PMO REMOVE LOCK CST
22 ELA UNIT IDLE SCF 022N02350
23
24
25 SHAFT PICK UP SCF
27 PBA SCF COVER OPEN 140N63025
28 ELA HOU CST SENSOR
29 PHOTO INTERRUPTER
30 PMO ACTUATOR EMPTY, SCF 120N00520
31 GEAR SCF PICK UP CAM 007N01366

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
