Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-31
Parts List
PL 2.3 Duplex Assembly Parts List Table
Item No. Description Part Number
0 ELA UNIT DUPLEX 022N02412
1 FRAME M DUPLEX
2 GUIDE M UPPER DUP
3 COVER M REAR DUP
4 MEA ETC ALIGN DUP
4-1 GUIDE M ALIGN DUP
4-2 SHAFT IDLE ROLL DUP
4-3 ROLLER M IDLE DUP
4-4 PCT SLIP WASHER
4-5 SPRING ETC DUP
4-6 PULLEY M 18 DUMMY DUP
4-7 PULLEY 18 DUP
4-8 BUSH M FEED DUP
4-9 BELT TIMMING
4-10 ROLLER FEED DUP
4-11 RING C
5 CAP M CONNECTOR DUP
6 DUCT M FAN DUP
7 FAN DC HAWK
8 PBA SUB DPX SCF
9 CABLE CLAMP
10 IPR TERMINAL GND DUP
11 LOCKER M DUP
12 SHEET FRAME DUP
13 SPRING TS
14 PMO ACTUATOR FEED DUP
15 PBA SUB MP SEN (Duplex Exit sensor)
16 CBF HARNESS POWER GND
17 MOTOR STEP
18 BRACKET P MOTOR DUP
19 PULLEY M 30 DUP
20 BELT TIMING GEAR
21 PULLEY M 30 DUMMY DUP
22 RING E
23 CBF HARNESS D JOINT

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
