Index
A
Access Door, disassembly, 7-12
acronyms and abbreviations, A-2
B
black print defects, 5-13
blank print defects, 5-9
C
Center Loading Process, 2-7
charge roller, 2-2
cleaning, 2-2
Laser Scan Unit, 6-3
printer, 6-2
Cleaning blade, 2-3
Clutches/Solenoid tests, 3-9
Consumables, 1-3
contamination defects, 5-15
Control, 7-6
Control Panel
components
, 1-5
disassembly, 7-13
LED, 1-5
menu map, 1-5
messages, 1-5
Controller Unit to Main Board Wiring Diagram, 9-17
Cooling Supply Fan, disassembly, 7-73
coordinates column for designators, 9-2
Cover Assembly
Cover Open Board and Sensor
, 2-16
Cover Open Sensor, disassembly, 7-74
Cover status, 3-5
parts list, 8-11
view of parts, 8-10
D
Developer Drive, disassembly, 7-51
Developing Motor, 2-7
Device control tests, 3-10
Diagnostic Menu Map, 3-5
Disassembly
general notes
, 7-2
notation, 7-5
Drum, 2-3
Duplex Assembly, 2-9
disassembly, 7-37
Duplex paper path, 2-5
Duplex Roller, disassembly, 7-47
Duplex Unit Sensor, 2-16
parts list, 8-31
view of parts, 8-30
Duplex board to Main Board Wiring Diagram, 9-17
E
ENERGY STAR, 1-ii
error message list, 3-11
Exit Assembly
Exit Gear, disassembly
, 7-44
Exit Roller, disassembly, 7-44
Exit rollers, 2-5
Exit Solenoid, disassembly, 7-48
F
faded image defects, 5-18
Fan tests, 3-9
fastener types
Posi-Drive screw types
, 7-4
precautions, 7-4
Feed Assembly
Feed Roller
, 2-5
Feed Sensor, 2-5
Idle Unit, disassembly, 7-49
process, 2-7
Frame Assembly
parts list
, 8-13
view of parts, 8-12
Functional specifications, 1-7
Fuser Assembly, 2-5, 2-8
defects, 5-3
disassembly, 7-54
Exit Sensor theory, 2-16
Fuser control tests, 3-9
Fuser Exit Sensor, disassembly, 7-56
Fuser Interlock Switch, disassembly, 7-55
parts list, 8-21
view of parts, 8-20
G
general wiring diagram, 9-12
ghosting defects, 5-16
