Xerox Phaser 3600 Service Manual

1-8 Phaser 3600 Printer Service Manual
General Information
Print Quality
Property Characteristic Specification
Resolution Normal Up to 1200 x 1200 dpi effective output
Line Width @ 600dpi
Line Width @ 1200dpi
Dot Diameter @ 600dpi
Dot Diameter @ 1200dpi
RET Yes
Halftone (Gray Scale) 256 levels
Blackness >1.20
Homogeneity of Halftone at five points on page must be 0.1
Halftone 20 % = 0.17 50 % = 0.49 80 % = 0.91
Printable Area Letter 208 x 271 mm
A4 200 x 289 mm
Non-Printable Area Envelope 10mm(0.4") from edge(Top/Bottom/Left/Right)
Other Media 4mm(0.16") from edge(Top/Bottom/Left/Right)
Toner Fixing Black (100% Solid) 80%
Halftone 70%
Magnification Horizontal (applied to
17
7.8m
m length)
< 1.0 mm (0.04 ) ( 0.5 % )
Vertical (applied to
241.3m
m length)
< 3.0 mm (0.12 ) ( 1.2 % )
Printing Skew Tray 1 (MPT)
< 1.5 mm (0.06 ) Simplex & Horizontal
< 2.0 mm (0.08 ) Duplex & Horizontal
< 2.0 mm (0.08 ) Simplex & Vertical
< 2.5 mm (0.10 ) Duplex & Vertical
Tray 2
< 1.5 mm (0.06 ) Simplex & Horizontal
< 2.0 mm (0.08 ) Duplex & Horizontal
< 2.0 mm (0.08 ) Simplex & Vertical
< 2.5 mm (0.10 ) Duplex & Vertical
Optional Tray 3
< 2.0 mm (0.08 ) Simplex & Horizontal
< 2.5 mm (0.1 ) Duplex & Horizontal
< 2.5 mm (0.10 ) Simplex & Vertical
< 3.0 mm (0.12 ) Duplex & Vertical

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
