Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 1-11
General Information
Optional Cassette
Tray
Capacity 500 sheets@75g
Media sizes A4/A5/Letter/Legal/Executive/Folio/
Oficio
/ISO B5/JIS B5
Media types Plain paper
Media weight 16~28lb (60 to 105g/)
Sensing Paper Empty Sensor
Duplex Supporting Optional
Media sizes A4/Letter/Legal/Folio/Oficio
Media types Plain paper
Media weight 20~24lb (75 to 90g )
Media Input Size/Weight
Source Media Types Media Sizes Media Weights
Tray 1 Paper, Envelope,
P
a
per Labels,
Transparency.
A4, Letter, Legal, Folio,
Executive, ISO and JISB5, A5
16 lb. ~ 28 lb.
(60 ~ 176 gsm)
Tray 2 Paper, Cardstock
Min: 76 mm x 127
mm
(3 in. x 5 in.)
Max: Legal
A4, Letter, Legal, Folio,
Executi
ve, IS
O and JISB5, A5,
A6, Statement Monarch, COM
10, C5, DL, 3” x 5”
16 lb. ~ 43 lb.
(60 ~ 105 gsm)
65# Cover
Tray 3 Paper A4, Letter, Legal, Folio,
Executi
ve, ISO and
JISB5, A5
16 lb. ~ 28 lb.
(60 ~ 105 gsm)
Duplex Paper A4, Letter, Legal, Folio 20 lb. ~ 24 lb.
(75 ~ 90 gsm)
Media Print Speed
Property Mode Specification
Speed Simplex Up to 38 ppm in A4
(40 pp
m in Letter)
Duplex 26 ipm in A4 (27
ip
m in Letter)
(Letter A4 Folio
Of
icio Legal)
First-Page Output Time
(FPOT)
from standby Less than 9 sec
from sleep/power save mode Less than 40 sec
from cold status Less than 49 sec
Warm Up Time from sleep/power save mode Less than 31 sec
from cold status Less than 40 sec
Media Tray Capacity

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
