Xerox Phaser 6120 Service Manual

Error Codes and Messages Index
Phaser® 6120 Color Laser Printer Service Manual
4-13
15 Transfer Belt, Cleaning Blade
pressure/retraction failure
The state of the Retraction Position Sensor/Cleaning Blade
is not changed from the blocked to unblocked state even
after the lapse of a predetermined period of time during
predrive.
The Retraction Position Sensor/Cleaning Blade is in the
blocked state even after the lapse of a predetermined
period of time during predrive.
The Retraction Position Sensor/Cleaning Blade is not
unblocked (blade in the retracted position) within a
predetermined period of time after the retraction sequence
of the Cleaning Blade has been started.
The Retraction Position Sensor/Cleaning Blade is not
blocked (blade in the pressed position) within a
predetermined period of time after the pressure sequence
of the Cleaning Blade has been started.
16 Transfer Belt rotation failure The Belt Positioning Sensor does not detect the Transfer
Belt position detection hole a second time even after the
lapse of a predetermined period of time after it has
detected one while the Transfer Belt is rotated.
17 Toner carousel rotation failure The Rack Positioning Sensor is in the blocked state when
the Rack Motor remains de-energized.
The Rack Positioning Sensor is not blocked a second time
even after the lapse of a predetermined period of time after
it has been blocked once while the Rack Motor remains
energized.
The Rack Positioning Sensor is unable to detect the
deceleration control position after the lapse of a given
period of time after the Rack Motor has started while the
Rack Motor is turning.
The count value of the edge of ON signal of the Rack
Positioning Sensor during each developing positions are
not a predetermined value while the Rack Motor is turning.
18 Fuser warm-up heating roller
failure
The Thermistor does not detect a predetermined
temperature value even after the lapse of a predetermined
period of time after the current warm-up cycle has been
started and the current warm-up cycle is thus not
completed.
19 Fuser low temp error The temperature detected by the Thermistor remains lower
than a predetermined value for a predetermined period of
time.
1A Fuser overheat error The temperature detected by the Thermistor is a
predetermined value or higher for a predetermined period
of time.
1B Fuser faulty thermistor The condition of a temperature rise of less than 1° C
extends continuously for a predetermined period of time
that begins when the warm-up cycle is started.
21 Faulty OHP Sensor It is determined that the OHP Sensor is faulty through a
check made at the end of the predrive.
23 Faulty Waste Toner Near Full
Detection Board
It is determined that the LED and photoreceiver are faulty
through a check made when a new Imaging Unit is
detected.
Code Description Detection Timing

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
