Xerox Phaser 6120 Service Manual

Index of Control Panel Messages
Phaser® 6120 Color Laser Printer Service Manual
3-6
Index of Control Panel Messages
Standard Status Messages
Normal state messages are displayed on the upper line of the LCD.
Message Description
READY Ready to print
WARMING UP Warming up
INITIALIZING The printer is being initialized.
ENERGY SAVER Energy Saver mode
CANCELLING JOB Canceling a job
PROCESSING A print job is being processed.
PRINTING
(XXX/XXX)
The machine is printing with the collating function.
IMAGE ADAPT
QUALITY DOWNGRADE
FIRMWARE UPDATE
WRITING IMAGE
The firmware is being updated.
FIRMWARE UPDATE
FORMATTING
UPDATE FIRMWARE
READING IMAGE
STARTING SYSTEM
FIRMWARE IMAGE
CALIBRATING Calibrating
Whenever you replace a toner cartridge or reboot the printer after making an
temperature/humidity environmental change, the printer automatically
pauses to do an Automatic Image Density Control (AIDC) cycle. This process
is provided to make reliable printer operation with optimum output quality
possible.
Warning Messages
Message Description
IMAGING UNIT LOW This message is displayed when the usage becomes 4% or under.
CYAN LOW This is displayed when the usage becomes 4% or less for 4.5K cartridge and
12% or under for 1.5K cartridge. And this status is cleared when the usage
becomes 0%.
MAGNETA LOW This is displayed when the usage becomes 4% or less for 4.5K cartridge and
12% or under for 1.5K cartridge. And this status is cleared when the usage
becomes 0%.
BLACK LOW This is displayed when the usage becomes 4% or less for 4.5K cartridge and
12% or under for 1.5K cartridge. And this status is cleared when the usage
becomes 0%.
YELLOW LOW This is displayed when the usage becomes 4% or less for 4.5K cartridge and
12% or under for 1.5K cartridge. And this status is cleared when the usage
becomes 0%.
DISK NEAR FULL The hard drive is nearly full.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
