Xerox Phaser 6120 Service Manual

General Information and Specifications
Phaser® 6120 Color Laser Printer Service Manual
9-2
General Information and Specifications
Product Specifications
Media Specifications
Machine Specifications
Operating Environment
Paper Size A4/Letter
Paper Type
Plain paper: 60 to 90 g/m
2
(16 to 24 lb.)
Note: Duplex Unit: Only plain paper and recycled paper weighing 75 to
90 g/m
2
(20 to 24 lb.) can be fed through the unit.
Recycled paper: 60 to 90 g/m
2
(16 to 24 lb.)
Power Requirements DC 24 V ± 10% (supplied from the main unit)
DC 5 V ± 5% (supplied from the main unit)
Max. Power
Consumption
42 W
Dimensions 370 (W) × 153 (D) × 327 (H) mm
14.6" (W) × 6.0" (D) × 12.9" (H)
Memory Requirements For full duplex printing capabilities, an additional 128 MBytes of
memory is required.
(The duplex option comes with one stick of 128 MBytes of RAM
included).
Weight Approx. 2.3 kg (5.1 lb.)
Temperature 10 to 35° C / 50 to 95° F (with a fluctuation of 10° C / 18° F or less per
hour)
Humidity 10% to 80% (with a fluctuation of 20%/h)

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
